6.0mm Fire Rated ACP with 0.3mm Alloy Layer for Retail Displays

ACP Featuring 0.3mm Alloy Layer – Fire Rated 6.0mm Sheets for Retail Displays

Company Overview

Since 1999, Foshan Nanhai Huashi Decoration Material Co., Ltd. has been a trusted manufacturer of aluminum composite panels (ACP) under the renowned “Richly Bound” brand. Backed by ISO 9001:2008 certification and equipped with advanced continuous extrusion lines, we supply innovative ACP solutions to industries worldwide. Our products are known for their safety, performance, and adaptability across architectural and commercial environments.

Product Overview

This 6.0mm Fire Rated ACP with 0.3mm aluminum alloy skins is purpose-built for retail display systems, combining structural rigidity, fire protection, and excellent surface adaptability. Designed for frequent public interaction and visual exposure, it offers long-lasting aesthetics and compliance with modern safety codes—ideal for shop fittings, branded environments, kiosks, and signage structures.

Key Features

1. A2 Fire Classification – Certified Safety
Compliant with GB 8624-2012, the panel is classified as A2-s1, d0, t0 after testing by the National Research Center of Testing Techniques for Building Materials:

• Non-combustible core with a calorific value of only 1.9 MJ/kg

• No flaming droplets (d0) and low smoke emissions (s1)

• Toxicity level: ZA1 – Quasi Safety Level-One, suitable for crowded commercial areas

• Thermal distortion temperature: 97°C

2. Enhanced Thickness for Display Durability

• Total panel thickness: 6.0mm, offering superior rigidity and strength for freestanding or wall-mounted display systems

• Aluminum skin thickness: 0.3mm front and back, providing excellent resistance to denting, flexing, and vibration

• Perfect for high-traffic retail zones and semi-permanent installations

3. Compatible with High-End Finishes

• Can be laminated, printed, painted, or textured with special effects (e.g., gloss, metallic, matte)

• Smooth surface ideal for digital printing or branding applications

• PVDF or polyester coatings (≥38μm) available for color retention and abrasion resistance

4. Excellent Mechanical Performance
Conforms to GB/T 17748-2016 standards:

• Bending strength: up to 124 MPa

• Peel strength: average 128 N·mm/mm, ensuring long-term layer integrity

• Shear strength: 30.4 MPa, supporting structural mounting

5. Easy Fabrication & Lightweight Advantage

• Despite its structural thickness, it remains significantly lighter than solid aluminum or steel

• Easy to cut, route, punch, fold, and install using standard tools

• Suitable for modular systems and rapid on-site assembly

• Compatible with screws, rivets, adhesives, and magnetic or mechanical fasteners

Application Scenarios

This panel is optimized for interior commercial display solutions, including:

• Retail store fixtures and branded displays

• Exhibition booths and portable product kiosks

• Signboards, POP stands, and advertising panels

• Back panels for shelving and cabinetry systems

• Showroom partitions and featured walls

• Event structures requiring fire-rated material

Conclusion

The ACP Fire Rated 6.0mm Sheets with 0.3mm Alloy Layer are the ideal choice for retail display systems that demand a strong, safe, and visually adaptable material. With certified A2-grade fire resistance, outstanding flatness, and versatile surface compatibility, this panel meets the practical and aesthetic needs of today’s retail and commercial environments.

For surface finish options, customization support, or technical documentation, please contact our team directly.
